| No. | Parameters | Kettle | Jacket | |
| 1 | Full volume（L） | 36 | ||
| 2 | Work volume（L） | 30 | ||
| 3 | Design pressure（MPa） | 4.8 | 0.1 | |
| 4 | Work pressure（MPa） | 4 | 0.1 | |
| 5 | Design temperature（℃） | 200 | 200 | |
| 6 | Work temperature（℃） | 150 | 150 | |
| 7 | Material | C-276+Q345R | Q345R | |
 |
Special contructure: The equipment is a reactor without agitator. Jacketed structure. Unique Material: Due to the high corrosive working conditions, the Hastelloy C276 is used as the clylinder internal material. And flange is lined with hastelloy C-276 too, because it is also contacting the reactants. |
| Customized flange pairs, gauges The other parts, such as valves, pipes, gauges, are also made from the Hastelloy. They are customized as per clients's detail request. |
 |
| Type | Structure | Design temperature | Stirring speed | Heating power | Discharging type | Mixing style | Contact material | Controller |
| / | Customized | 0 °C~800°C | N/A | 4~6KW | Top | N/A | Hastelloy C276 | PID |
| Volume | Design pressure | Motor | Motor power | Heating type | Mixer shaft | Seal type | Kettle lid open port | Other accessories |
| 30 L | Negative pressure ~15 Mpa | N/A | N/A | electric | Self-lubricating wear-resistance sleeve made of stainless steel | N/A | Burst disc(safety valve ) port, etc | Manual Lifting Support rack |
